| Technical data | Information | ||
|---|---|---|---|
|
Brand
|
MEAN WELL
|
Commodity
|
8504408390
|
|
Item number
|
HLG-600H-24A
|
Warranty pack
|
84 Months Bring-In
|
|
Series
|
HLG-600H
|
RoHS
|
Compliant
|
|
Description
|
AC-DC Single output LED driver Mix mode (CV+CC) with built-in PFC; Output 24Vdc at 25A; IP65; Cable output; CC/CV adjust with Potentiometer
|
Packing quantity
|
|
|
Application
|
ITE EN/UL/IEC 60950
LED EN 61347
|
Net weight (gram)
|
3940
|
|
Technology
|
AC/DC
Constant Current C.C.
Constant Power C.P.
Constant Voltage C.V.
|
||
|
Power Format
|
Box Type - Enclosed
Enclosed Metal housing
|
||
|
Output Power (W)
|
600
|
||
|
Output Voltage (V)
|
24
|
||
|
Output Current (A)
|
25
|
||
|
Input Voltage (V)
|
110/230 universal input
90 - 305
|
||
|
IP Rating
|
IP65
|
||
|
Width (mm)
|
144
|
||
|
Height (mm)
|
48.5
|
||
|
Depth (mm)
|
280
|
||
|
Control Signals
|
Potentiometer
|
||
|
Dimming Technology
|
Analog
Potentiometer
|
||
|
Housing Type
|
Metal
|
||
